Specifications
Power output: 200 watts RMS x 7 (all
channels driven simultaneously into 8 ohms from 20 Hz to
20 kHz with less than 0.05% total harmonic distortion).
300 watts RMS x 7 @ 4 ohms
Signal to Noise: >119dB below rated FTCfull bandwidth power
Power Bandwidth: 5 Hz - over 100 kHz
(+0/-3 dB)
Crosstalk: Greater than -100 dB from
20 Hz to 20 KHz
Intermodulation Distortion: Less than .03% from 250mV to full rated FTC power
Voltage gain: RCA 28dB.
Slew rate: 50 Volts/microsecond
Remote Trigger voltage: 3 - 32 volts
DC
Power requirements: 115 V 50-60 Hz
Power consumption: 1,800 watts (maximum)
Dimensions (W x H x D): 17.2 x 7.75
with feet x 18 (inches)
Weight: 90 (lbs)
|
