Specifications
Power output: 200 watts RMS x 5 (all
channels driven simultaneously into 8 ohms from 20 Hz to
20 kHz with less than 0.05% total harmonic distortion).
300 watts RMS x 5 @ 4 ohms
Signal to Noise: 119dB "A" weighted
Power Bandwidth: 5 Hz - over 100 kHz
(+0/-3 dB)
Damping factor: 850 (10 Hz - 400 Hz)
Input sensitivity/Impedance: 1.43 volts
for full output/28 k ohms.
Crosstalk: Greater than -90 dB from
20 Hz to 20 KHz
Gain: Voltage gain of 28 dB
Slew rate: 50 Volts/microsecond
Remote Trigger voltage: 3 - 32 volts
DC
Power requirements: 115 V 50-60 Hz
Power consumption: 1,800 watts (maximum)
Dimensions (W x H x D): 17.2 x 7.75
with feet x 18 (inches)
Weight: 78 (lbs)
|
